- Size: 18
- Place of Origin: China
- Brand Name: wuzheng
- Model Number: CK7YPJZ1675P-2
- Weight: 1840.000 kg
Model | CK7YPJZ1675P-1 | ||
Cabin | Aoxiang 1600 one and a half | ||
Main dimensions | Overall dimensions (LxWxH) | (mm) | 4830X1720X2050 |
Dimensions of the cargo body (LxWxH)mm | (mm) | 2600X1640X450 | |
Wheel base | (mm) | 3300 | |
Wheel track (front/rear) | (mm) | 1380 | |
Min. ground clearance | (mm) | 215 | |
Weight | Curb weight | (kg) | 1480 |
Rated payload | (kg) | 1500 | |
Persons in cab | (persons) | 2 | |
Gross vehicle weight | （kg） | 3470 | |
Overall performance | Max. speed | （km/h） | 49.2 |
Max. slope of climb | （%） | 15 | |
Min. turning radius | （m） | 4.67 | |
Engine | Engine Type | Ld brand，LL480B | |
Displacement | （L） | 1.809 | |
Rated horsepower | （kg.m/rpm） | 39.5 | |
Steering gear Type | Mechanical | ||
Service brake and boostingType | Air brake | ||
Wheels and tire sizes | Front wheel | 6.00-16 | |
Rear wheel | 7.50-16 | ||
Electric device | Rated voltage | V | 12 |
Battery | 6-QW-100MF | ||
Excellent driving comfort
Good looking streamlined cab with abundant space, good sealing and perfect sound insulation, soft seats, and well-made interior layout offer you a more comfortable driving experience.
High loading capacity
Thick dumping cargo offers high loading capacity.
Dumping
The dumping container with a lifting angle of not less than 45° can dump various kinds of goods fast and efficiently， within 20 s from the ground to lifting .
MP3
We also offer you a high quality MP3 music player inside the cab, in order to ease the fatigue of driver.
