- Size: 18
- Place of Origin: China
- Brand Name: wuzheng
- Model Number: CK7YPJZ1675P-2
- Weight: 1840.000 kg
Model | 7YPJ1156H6 | ||
Cabin | Aoxiang 1500 single | ||
Main dimensions | Overall dimensions (LxWxH)mm | (mm) | 4595×1595×1995 |
Dimensions of the cargo body (LxWxH)mm | (mm) | 2485×1630×1240（outside） 2300×1480×950（inside） | |
Wheel base | (mm) | 2860 | |
Wheel track (front/rear) | (mm) | 1240 | |
Weight | Curb weight | (kg) | 1180 |
Rated payload | (kg) | 490 | |
Persons in cab | (persons) | 2 | |
Gross vehicle weight | （kg） | 1700 | |
Overall performance | Max. speed | （km/h） | 49.2 |
Max. slope of climb | （%） | 15 | |
Min. turning radius | （m） | 3.78 | |
Engine | Engine Type | C1115E | |
Displacement | （L） | 1.194 | |
Rated horsepower | （kg.m/rpm） | 22 | |
Steering gear Type | Turbine | ||
Service brake and boostingType | Ail brake | ||
Wheels and tire sizes | Front wheel | 6.00-14 | |
Rear wheel | 7.00-16 | ||
Electric device | Rated voltage | V | 12 |
Battery | 6-QW-120MF | ||
Strong environment adaptability
Broad vision, compact structure, and short wheelbase, adding excellent mobility enable the vehicle adapt to different road conditions.
Dumping
With a dumping container and a lifting angle of not less than 45°, it can dump various kinds of goods, it can fast and efficiently deal with uploading and downloading within 20 s from the ground to lifting .
Outstanding maneuverability
Simple windshield design offers driver a good view. Steering system with worm steering device makes steering operation easier and more flexible, reduce driver’s labor intensity, and improve working quality.
