- Size: 100
- Place of Origin: china
- Brand Name: wuzheng
- Model Number: 4LZ-3.0Z
- Weight: 9000.000 kg
Main Features
1. Adopt HST of American Sauer Co., Ltd., which can realize continuous variable transmission of the complete vehicle.
2. Adopt semi-receiver structure as control mode, which makes the operation of moving forward and backward easy and convenient.
3. Adopt receiver beater + single longitudinal direction axial flow cylinder sheller system.
4. Adopt long 400×90×49mm continuous track.
5. The shear platform and the bridge are connected together, which can move up and down as a whole.
6. Adjustable opening of upper screener and adjustable angle of bottom screener.
7. The rotating speed of fan can be adjusted at definite ratio, which can fit the harvest requirement of various crops.
Technical parameters
| Engine power (ps) | 75 | Cutting width (mm) | 2000 |
|---|---|---|---|
| Feeding rate (kg/s) | 2 | Total loss rate (%) | (Wheat)≤1.2 (Rice)≤3.0 |
| Broken rate (%) | Wheat≤1.0 Rice≤1.5 | Impurity rate (%) | Wheat≤2.0 Rice≤2.0 |
| Threshing and cleaning structure type | Feeding wheel+single horizontal axis flow roller + fan + double layers shaking screen | Gravure plate adjustable structure | Adjust the position of threshing teeth |
| Axis flow roller(outer diameter*length) | ￠620*1854 | Grain tank capacity(m³) | 0.5/1.0 |
| Grain unloading type | Manual receiving grain | Running speed range(Km/h) | 0～8.579 |
| Operation weight | 2900±5% | Overall dimension (L*W*H) (mm) | ≤5115*2290*28 |
